Brief introduction：
EFC3062322 is a engine speed controller designed by all electronic device for 's actuator, It can fast and precise response to transient load changes. It ha...MORE >>
Classification：Speed Controller
Size：20X15X10 cm
Weight：1KG
Price：
Introduction
EFC3062322 is a engine speed controller designed by all electronic device for 's actuator, It can fast and precise response to transient load changes. It has a wide speed control range.
For these controllers, separate circuits allow adjustments of proportional, integral and derivative values. These parameters all work together to provide a control that results in fast and stable engine response to load changes while maintaining precise speed regulation of diesel.
Specification----
| 3062322 | |
| RPM Stability: | <±0.25% |
| Speed Range: | 1KHz ~ 6.5KHz |
| Thermal Stability: | Max ±0.7% |
| IDLE Regulation: | 260 ±20Hz |
| DROOP Regulation: | Minimum 15Hz ±6Hz/ 1 Amp |
| Maximum: 400Hz ±75Hz/ 1 Amp | |
| External Speed Regulation: | ±200Hz (with 1 KΩ connected) |
| AUX Input Sensitivity: | 148Hz / 1V., ±10Hz |
| Impedance: | 1MΩ |
| Working Temp Range: | -40 ~ 85 °C |
| ENVIRONMENT: | |
| Working Humidity Range: | Maximum 95% |
| Stocking Temp: | -55 ~ 92 °C |
| Shocking: | 20-100HZ 500mm/Sec. |
| INPUT POWER SUPPLY: | |
| Voltage: | 12 or 24V |
| Grounding Pole: | Negative pole |
| Power Supply: | 40mA |
| Actuator Continuous Current: | Minimum 1A, Maximum 4.5A |
| MPU | |
| Signal: | 2 ~ 120V RMS |
