The module offers electronic (CAN) and non-electronic (magnetic pick-up/alternator sensing) engine versions and offer a number of flexible inputs, outputs and engine protections so the system can be easily adapted to suit a wide range of application demands.

The module can be easily configured using the DSE Configuration Suite PC software. Selected front panel editing is also available.

KEY FEATURES

• CAN and magnetic pick-up/Alt.sensing versions (specify on ordering)
• 3 phase generator monitoring
• Four digital inputs/three analogue inputs
• Six outputs (all six configurable on CANbus version, four configurable on magnetic pickup version)
• Three phase sensing
• Event log (5)
• 50/60 Hz calibration setting
• Configurable timers
• Automatic shutdown or warning when fault conditions are detected
• Overspeed protection
• Manual and remote start

• Engine pre-heat
• Protected Solid State Outputs(PSS)
• Advanced metering capability
• Front panel/PC programming
• Hours counter
• LED indicators
• Back-lit character icon LCD displa
