Brief introduction:
3037359 Compatible with Compatible with speed actuatorspeed control unit 3037359speed control suitable for generarorSemiconductor power devices : All imported I...MORE >>
Classification:Speed Controller
Size:20X15X10 cm
Weight:1KG
Price:
Introduction
speed control suitable for generaror
Semiconductor power devices : All imported IC
RPM Stability | <±0.25% |
Speed Range | 1KHz ~ 6.5KHz |
Thermal Stability | Max ±0.7% |
IDLE Regulation | 260 ±20Hz |
DROOP Regulation | Minimum 15Hz ±6Hz/ 1 Amp |
Maximum: 400Hz ±75Hz/ 1 Amp | |
External Speed Regulation | ±200Hz (with 1 KΩ connected) |
AUX Input Sensitivity | 148Hz / 1V., ±10Hz |
Impedance | 1MΩ |
Working Temp Range | -40 ~ 85 °C |
ENVIRONMENT | |
Working Humidity Range | Maximum 95% |
Stocking Temp | -55 ~ 92 °C |
Shocking | 20-100HZ 500mm/Sec. |
INPUT POWER SUPPLY | |
Voltage | 24V |
Grounding Pole | Negative pole |
Power Supply | 40mA |
Actuator Continuous Current | Minimum 1A, Maximum 4.5A |
MPU | |
Signal | 2 ~ 120V RMS |
