MAIN FEATURES

DSE9155 30volt 2amp DC Battery Charger

ADVANCED FEATURES

Multi-Stage Intelligent Charging
• Constant current- Maximum
current available during charge
recovery phase
• Constant voltage
• Chargers automatically return to float mode when charging is complete

Low Output Ripple
• Makes the chargers ideal for all
battery types

Full Protection
• Reverse polarity protection, short circuit protection and current limiting
• Automatic recovery after the removal of fault conditions

Boost Mode
• Boosts and equalises cell charge improving battery performance and life
• Simple boost connection using on-board terminals

Power Save Mode
• Once the battery is fully charged the chargers switch to Eco-Power to save energy

KEY BENEFITS

• Suitable for a wide range of battery types
• No moving parts for longer battery charger life
• Switched mode design
• Charge fail output
• Minimum 80% efficiency throughout full operating range

Paralleling Feature
• Multiple modules can be linked together to provide larger current output

SPECIFICATION

AC SUPPLY

VOLTAGE RANGE
85 V to 265 V (L-N)

DC OUTPUT
2 A DC 30 V DC at 34.3 V DC

RIPPLE AND NOISE
<1%

EFFICIENCY
>80%

REGULATION

LINE
<0.001% Vo
LOAD
1% Vo

PROTECTIONS
Short Circuit
Over Voltage
Over Current
Reverse Polarity

DIMENSIONS

OVERALL
136 mm x 140 mm x 63 mm
5.4” x 5.5” x 2.5”

WEIGHT
0.5 kg
