ADVR-073 KUTAI AVR Automatic Voltage Regulator

Hybrid Universal Analog Digital Voltage Regulator 7Amp
ADVR-073 is an Hybrid Analog/Digital Voltage Regulator. It's desigined with CPU inside which eliminates voltage drifting that caused by temperature variation. This designed has greatly improves the reliability of AVR. ADVR-073 has over excitation and loss of sensing shutdown protections which will prevent AVR from damaging in overload situatio

Features

• Voltage regulation less than +/-0.5%
• 220/380/440/480 Vac programmable input
• Rugged compact design
• With under frequency protection
• Over excitation protection
• Soft start voltage ramping
• EMI suppression
• Built-in high capacity 8Amp fuse

• Specifications

  • Sensing Input
  • Voltage 170 to 520 Vac 1 phase 2 wire DIP switch selectable
    Frequency 50/60 Hz DIP switch selectable

  • Power Input
  • Voltage 100 to 300 Vac 1 phase 2 wire

  • Output
  • Voltage Max. 63 Vdc @ 220 Vac input
    Current Continuous 7A
    Intermittent 15A for 10 seconds
    Resistance Min. 9 ohms
    Max. 100 ohms

  • Voltage Regulation
  • Less than +/-0.5% (with 4% engine governing)

  • Build Up Voltage
  • Residual volts at AVR terminal more than 5 Vac

  • Over Excitation Protection
  • 78 +/-5 Vdc @ 220 Vac 5 seconds

  • External Voltage Adjustment
  • 7% with 1K ohms 1 watt potentiometer

  • Static Power Dissipation
  • Max. 8 watts

  • Soft Start Ramp Time
  • 3 seconds

  • EMI Suppression
  • Internal electromagnetic interference filtering

  • Voltage Thermal Drift
  • 0.03% per °C change in AVR ambient

  • Under Frequency Protection (Factory Presets)
  • 50 Hz system presets knee point at 45 Hz
    60 Hz system presets knee point at 55 Hz

  ---

  AVR Control Functions

  • VOLT
  • Voltage adjustment

  • STAB
  • Stability adjustment

  • U/F
  • Setting under frequency protection knee point

  ---

  Indication LED

  • O/E
  • Over excitation protection indicator

  • U/F
  • Under frequency protection indicator

  ---

  Environment

  • Operating Temperature
  • -40 to +60 °C

  • Storage Temperature
  • -40 to +85 °C

  • Relative Humidity
  • Max. 95%

  • Vibration
  • 3.0 Gs @ 100 to 2K Hz

  ---

  Physical Specifications

  • Dimensions
  • 150.0 (L) x 115.0 (W) x 51.0 (H) mm

  • Weight
  • 440 g +/-2%
